Electra 6mm 4 Core + Earth Orange Flexible Cable V-90 PVC/V-90 PVC

Description

Flexible Cable, 6 mm, Annealed Copper, 250-440 Volt, 40 Amp, 4 Core + Earth, 84/0.3 mm Strands, 16.1 mm Overall Diameter, 0.8 mm Insulation Thickness, 1.5 mm Sheath Thickness, DC: 3.3 Ohm/km Conductor Resistance, Brown/Blue/White/Red/Green/Yellow Core, V-90 PVC Insulation, V-90 PVC Sheath, Orange Sheath, 90 deg C, AS/NZS 1125 AS/NZS 3808 AS/NZS 3191

Key Specifications

SKU	ELCF5060-OR
Brand	Electra
Product Type	Flexible Cable

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	100
UNSPSC Class	26121600
UOM	MTR
Vendor Product	F5060-OR
Conductor Resistance	DC: 3.3 Ohm/km
Conductor Size	6 mm
Conductor Type	Annealed Copper
Core Colours	Brown/Blue/White/Red/Green/Yellow
Current	40 Amp
Insulation Material	V-90 PVC
Insulation Thickness	0.8 mm
Number of Cores	4 Core + Earth
Overall Diameter	16.1 mm
Sheath Colour	Orange
Sheath Material	V-90 PVC
Sheath Thickness	1.5 mm
Standards	AS/NZS 1125 AS/NZS 3808 AS/NZS 3191
Stranding	84/0.3 mm
Temperature	90 deg C
Voltage	250-440 Volt
