Outlet Mech Cat5e UTP RJ45 30 Mech T568A/B Black

Clipsal Actassi S-110 Outlet Mechanism Modular Jack Cat5e UTP RJ45 30 Mech T568A/B Black

PRODUCT CODE:
CLI30RJ45SMA5CBK
Std Pack Size
1
OUR P/N:
CLI30RJ45SMA5CBK

You need to be registered and logged in to view product details and pricing

Outlet Mechanism Cat5e UTP, 1000 Volt AC/DC, 1.5 Amp, 24-23 AWG, RJ45 Connector, Cat5e UTP Cable, 8 Pins, >= 500 MOhm at 100 Volt DC Insulation Resistance, 20 mOhm Contact Resistance, 750 Cycles Durability, 1-100 MHz Bandwidth, Wiring Scheme: TIA-568A/B, S-110 30 Mech Outlet Mechanism, Flammability: UL94-V0, ABS + PC Housing, Copper Alloy Contact Base, Gold Plated Contact Plating, Black,-10 to 60 deg C, 36mm Length, 22mm Height, 16mm Width

Additional Information

Additional Information
Brand Clipsal
Range Name RJ45
Standard Pack Size 1
UNSPSC Class 43223300
UOM EA
Vendor Product 30RJ45SMA5C-BK
Contact Plating Material Gold Plated
Contact Resistance 20 mOhm
Height 22mm
Temperature -10 to 60 deg C
Product Type Outlet Mechanisms Cat5e
Connector RJ45
Conductor Size 24-23 AWG
Outlet Type S-110 30 Mech
Width 16mm
Contact Base Material Copper Alloy
Colour Black
Flammability UL94-V0
Durability 750 Cycles
Wiring Scheme TIA-568A/B
Insulation Resistance >= 500 MOhm at 100 Volt DC
Length 36mm
Number of Pins 8 Pin
Frequency Bandwidth 1-100 MHz
Cable Type Cat5e UTP
Housing Material ABS + PC
Current 1.5 Amp
Voltage 1000 Volt AC/DC
