Garland Pro Series UTP Data Cable Cat5e 4 Pair 24AWG Polyethylene/LSZH Green 305M

Description

CAT 5e Data Cable UTP, 24 AWG/0.2 mm, 0.5 mm Conductor Diameter, 93.8 Ohm/km Conductor Resistance, 1/0.5 mm Strands, 1000 MOhm/km Insulation Resistance, 0.2 mm Insulation Thickness, 0.5 mm Sheath Thickness, Cat 5e UTP, 4 Pair, 54 mm Installation Bend Radius, 111 N Max. Pulling Force, Annealed Copper Conductor, Rip Cord: Polyester Multi Yarn Filler, Polyethylene Compound Insulation, LSZH Sheath, Cream Sheath, 15 to 70 deg C, 305 mtr Length, 5.1 mm Outside Diameter

Key Specifications

Barcode (EAN-13)	9329849019938
SKU	GARUTPL5EHFGN305B
Brand	Garland

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	305
UNSPSC Class	26121600
UOM	MTR
Vendor Product	UTPL5EHFGN305B
Cable Type	Cat 5e UTP
Bend Radius	54 mm Installation
Conductor Diameter	0.5 mm
Conductor Resistance	93.8 Ohm/km
Conductor Size	24 AWG/0.2 mm
Conductor Material	Annealed Copper
Filler Material	Rip Cord: Polyester Multi Yarn
Insulation Resistance	1000 MOhm/km
Insulation Thickness	0.2 mm
Insulation Material	Polyethylene Compound
Max. Pulling Force	111 N
Pair Count	4
Outside Diameter	5.1 mm
Sheath Colour	Cream
Sheath Material	LSZH
Sheath Thickness	0.5 mm
Stranding	1/0.5 mm
Temperature	15 to 70 deg C
