Legrand LED Emergency Exit Sign Single/Double Sided 3W Maintained Ceiling/Wall/Cantilever White PICTO All Inserts IP20

Description

Emergency LED Exit Sign Single/Double Sided, 3 Watt, 230-240 Volt AC Input Voltage, 50 Hz Input Frequency, LED, 24 mtr Viewing Distance, 50000 hrs, Maintained Operating Mode, Ceiling/Wall/Cantilever Mounting, IP20, Lithium-Ion with PCM-B 6.4 Volt 0.57 Ah, ABS, White, 10 to 40 deg C

Key Specifications

Barcode (EAN-13)	9321001458333
SKU	LEG686200/LI
Brand	Legrand
Range Name	Slide Connect
Product Type	Emergency Exits

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Retrofits to previous generation minitronics slide connect bracket One box solution Large terminal block for ease of connection Low cost maintenance iSmart temperature sensing technology for Li-ion battery Electronics designed to lengthen the life of the battery, minimising maintenance costs Environmentally friendly battery
Standard Pack Size	1
UNSPSC Class	39111700
UOM	EA
Vendor Product	686200/LI
Average Lamp Life	50000 hrs
Colour	White
Input Frequency	50 Hz
Input Voltage	230-240 Volt AC
Lamp Type	LED
Material	ABS
IP Rating	IP20
Operating Mode	Maintained
Mounting Method	Ceiling/Wall/Cantilever
Viewing Distance	24 mtr
Temperature	10 to 40 deg C
Wattage	3 Watt
