Forked Spade Insulated SGrip 1.5-2.5mm M5 Stud Blue

Panduit Locking Forked Spade Insulated Single Grip 1.5-2.5mm M5 Stud Blue 24.6mm OAL

PRODUCT CODE:
PANEV14-10LFB-L
Std Pack Size
50
OUR P/N:
PANEV14-10LFB-L

You need to be registered and logged in to view product details and pricing

Locking Forked Spade Terminal, Insulated, Single Grip, Conductor Size: 1.5-2.5 mm, Stud Size: M5, Terminal Type: Spring, Snap, 600 Volt Maximum, Wire Strip Length: 7.9mm, Barrel Type: Bevelled, Serrated, Seam Type: Butted, Mounting Method: Free Hanging, Body Material: Copper, Conductive Material: Copper, Insulation Material: Vinyl, Blue Insulation, Tin Plated Finish, 221 deg F, 24.6mm Overall Length, 12.3mm Lug Length, 8.4mm Lug Width, 0.8mm Lug Thickness, 4.83mm Lug Inside Width, Barrel Length: 12.3mm, Max. Insulation Diameter: 4.3mm, 50 Pack

Additional Information

Additional Information
Brand Panduit
Range Name StrongHold
Standard Pack Size 50
UNSPSC Class 39121400
UOM EA
Vendor Product EV14-10LFB-L
Barrel Type Bevelled/Serrated
Barrel Length 12.3mm
Body Material Copper
Conductive Material Copper
Conductor Size 1.5-2.5mm
Finish Tin Plated
Insulation Diameter 4.3mm
Insulation Material Vinyl
Insulation Colour Blue
Lug Inside Width 4.83mm
Lug Length 12.3mm
Lug Thickness 0.8mm
Lug Width 8.4mm
Mounting Method Free Hanging
Overall Length 24.6mm
Pack Size 50 Pack
Product Type Forked & Ring Terminals
Seam Type Butted
Stud Size M5 Stud
Temperature 221 deg F
Terminal Type Spring/Snap
Wire Strip Length 7.9mm
Voltage Rating 600 Volt
