Panduit Forked Spade Insulated Single Grip 1.5-2.5mm M4 Stud Blue 22.9mm OAL

$Panduit\Panduit_EV14-8FB-L.jpg$

Description

Forked Spade Terminal, Insulated, Single Grip, Conductor Size: 1.5-2.5 mm, Stud Size: M4, Terminal Type: Standard, 600 Volt Maximum, Wire Strip Length: 7.9mm, Barrel Type: Funnel, Seam Type: Butted, Mounting Method: Free Hanging, Body Material: Copper, Conductive Material: Copper, Insulation Material: Vinyl, Blue Insulation, Tin Plated Finish, 221 deg F, 22.9mm Overall Length, 11.4mm Lug Length, 7.9mm Lug Width, 0.8mm Lug Thickness, 4.32mm Lug Inside Width, Barrel Length: 11.4mm, Max. Insulation Diameter: 4.3mm, 50 Pack

Key Specifications

SKU	PANEV14-8FB-L
Brand	Panduit
Range Name	StrongHold
Product Type	Forked & Ring Terminals

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	50
UNSPSC Class	39121400
UOM	EA
Vendor Product	EV14-8FB-L
Pack Size	50 Pack
Conductor Size	1.5-2.5mm
Lug Inside Width	4.32 mm
Overall Length	22.9 mm
Body Material	Copper
Finish	Tin Plated
Temperature	221 deg F
Terminal Type	Standard
Barrel Type	Funnel
Lug Thickness	0.8 mm
Lug Length	11.4 mm
Lug Width	7.9 mm
Mounting Method	Free Hanging
Wire Strip Length	7.9 mm
Insulation Colour	Blue
Insulation Material	Vinyl
Barrel Length	11.4 mm
Stud Size	M4 Stud
Conductive Material	Copper
Insulation Diameter	4.3 mm
Seam Type	Butted
Voltage Rating	600 Volt
