APEC 25mm SDI Cable 500mtr

Description

SDI Cable, 25 mm, Annealed Copper, 0.6-1 kV, 1 Core, 19/1.35 mm Strands, 12 mm Overall Diameter, 500 mtr Length, 1.2 mm Insulation Thickness, 1.4 mm Sheath Thickness, V-90 PVC Insulation, White Insulation, V-90 PVC Sheath, White Sheath, 90 deg C, AS/NZS 5000.1

Key Specifications

Barcode (EAN-13)	932666301533
SKU	APEVVM025WW-5
Brand	APEC
Product Type	SDI Cable

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	500
UNSPSC Class	26121600
UOM	MTR
Vendor Product	VVM025WW-5
Conductor Size	25 mm
Conductor Type	Annealed Copper
Insulation Colour	White
Insulation Material	V-90 PVC
Insulation Thickness	1.2 mm
Number of Cores	1 Core
Overall Diameter	12 mm
Sheath Colour	White
Sheath Material	V-90 PVC
Sheath Thickness	1.4 mm
Standards	AS/NZS 5000.1
Stranding	19/1.35 mm
Temperature	90 deg C
Voltage	0.6-1 kV
