Belden RG8 Coaxial Cable Quad Ethernet 12AWG Yellow 305M

Description

RG8 Coaxial Cable Quad Ethernet, 300 Volt, 12 AWG, Bare Copper, 0.086 in Conductor Diameter, Bend Radius: 4.25 in, Pulling Tension: 255 lb, Stranding: Solid, Conductor Resistance: 1.42 Ohm/1000 ft, Capacitance: Conductor to Shield: 26 pF/ft, 50 +/-2 Ohm Impedance, Tinned Copper 94/90% Coverage Braid, Foam Polyethylene Insulation, PVC Sheath, Tri-Laminate (Alum+Poly+Alum) 100% Coverage Screen, Yellow Sheath, 0.405 in Overall Diameter, 305 mtr Length,-40 to 60 deg C

Key Specifications

SKU	BEL9880R305YW
Brand	Belden
Product Type	Coax Cable

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	305
UNSPSC Class	26121600
UOM	MTR
Vendor Product	9880 0601000
Braid Material	Tinned Copper 94/90% Coverage
Bend Radius	4.25in
Capacitance	Conductor to Shield: 26 pF/ft
Conductor Diameter	0.086 in
Conductor Resistance	1.42 Ohm/1000 ft
Conductor Size	12 AWG
Conductor Type	Bare Copper
Insulation Material	Foam Polyethylene
Overall Diameter	0.405 in
Screen Material	Tri-Laminate (Alum+Poly+Alum) 100% Coverage
Pulling Tension	255 lb
Sheath Colour	Yellow
Sheath Material	PVC
Stranding	Solid
Temperature	-40 to 60 deg C
