IPD Fuse Link HRC Clip In Blade 125A 500VAC 120kA Class gG DIN Size 00
Loading...
Description
Clip-In Blade Fuse Link HRC, 500 Volt AC, 125 Amp, 120 kA Interrupt Capacity, Screw Connection, Class gG, 59.5 mm Height x 29.5 mm Width x 79 mm Depth, DIN Size 00
Key Specifications
| Barcode (EAN-13) |
8430399001159
|
|---|---|
| SKU |
EEFNHG00-125
|
| Brand |
IPD
|
| Range Name |
NH DIN Fuses
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Features |
|
|---|---|
| Standard Pack Size | 3 |
| UNSPSC Class | 39121600 |
| UOM | EA |
| Vendor Product | NHG00-125 |
| Current | 125 Amp |
| Connection Type | Screw |
| Dimensions | 59.5 mm Height x 29.5 mm Width x 79 mm Depth |
| Interrupt Capacity | 120 kA |
| Standard Reference | DIN Size 00 |
| Utilisation Category | Class gG |
| Voltage | 500 Volt AC |
