Austech Flexible Wire Single Insulated 1 Core 1mm 0.6/1kV Tinned Copper V90HT PVC Brown

Description

Flexible Cable, 1 mm, Tinned Copper, 0.6-1 kV, 10 Amp, 1 Core, 32/0.2 mm Strands, 2.95 mm Overall Diameter, 0.8 mm Insulation Thickness, DC: 20 Ohm/km Conductor Resistance, V-90HT PVC Insulation, Brown Insulation, Unsheathed Sheath, Static -35 to 105 deg C, AS/NZS 3008.1 AS/NZS 3191 AS/NZS 1125

Key Specifications

SKU	ELEFHDT132020N100
Brand	ElectCables
Product Type	Flexible Cable

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	100
UNSPSC Class	26121500
UOM	MTR
Vendor Product	FHDT132020N100
Conductor Resistance	DC: 20 Ohm/km
Conductor Size	1 mm
Conductor Type	Tinned Copper
Current	10 Amp
Insulation Colour	Brown
Insulation Material	V-90HT PVC
Insulation Thickness	0.8 mm
Overall Diameter	2.95 mm
Number of Cores	1 Core
Sheath Material	Unsheathed
Standards	AS/NZS 3008.1 AS/NZS 3191 AS/NZS 1125
Stranding	32/0.2 mm
Temperature	Static -35 to 105 deg C
Voltage	0.6-1 kV
