Elcon High Temperature SDI Flexible Wire 1 Core 185mm 0.6/1kV X-HF-110/PVC +110C Black

Description

Flexible Wire, Double Insulated, High Temperature, 1 Core, 185 mm, Class 5 Plain Annealed Copper, 0.6/1 kV, 644 Amp, 24.7 mm Overall Diameter, 1.6 mm Insulation Thickness, 1.8 mm Sheath Thickness, Insulation Resistance: DC - 0.104 Mohm/m, X-HF-110 Insulation, Nitrile Modified PVC (NBR) Sheath, Black Sheath, 110 deg C

Key Specifications

SKU	ELNCHF-LHDN185BM
Brand	Elcon Cables
Product Type	Flexible Cable High Temperature Double Insulated

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	RoHS Compliant Excellent Flexibility Flame retardant Low flame propagation 99.9% OFHC (Oxygen Free High Conductivity) copper which does not show any brittleness
Standard Pack Size	100
UNSPSC Class	26121600
UOM	MTR
Vendor Product	CHF-LHDN185BM
Conductor Type	Class 5 Annealed Copper
Conductor Size	185 mm
Current	644 Amp
Insulation Material	X-HF-110
Insulation Resistance	DC: 0.104 Mohm/m
Insulation Thickness	1.6 mm
Sheath Colour	Black
Overall Diameter	24.7 mm
Number of Cores	1 Core
Sheath Material	Nitril Modified PVC (NBR)
Sheath Thickness	1.8 mm
Temperature	110 deg C
Voltage	0.6-1 kV
