Heinelec Combination RCD Circuit Breaker RCBO 4Pole 80 Amp 115 to 240VAC 6 kA DIN Rail Surface Mount

Description

Combination RCD Circuit Breaker RCBO, 80 Amp, 115 to 240 Volt AC, 50/60 Hz, Interrupt Capacity: 6 kA, Trip Sensitivity: 500 mA, Number of Poles: 4, 0.75 to 35 mm Terminal Connection, Shrouded Line and Load, IP2X, DIN Rail, Surface,-40 to 85 deg C, 119.5mm Height, 80mm Width, 116.4mm Depth

Key Specifications

SKU	HEISM36A80-500
Brand	Heinelec
Product Type	Combination RCBO

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Provides 30mA residual current protection Switches both the active and neutral poles Hydraulic-magnetic RCD Overcurrent trip point unaffected by ambient temperature Immune to pulsating DC 100% rating capability independent of amibent temperature Precision tripping characteristics Three pole plus switched netural each leakage protection switches all active and neutral each leakage protection switches all active and neutral poles Immune to pulsating DC load current Reset immediately after overload
Standard Pack Size	1
UNSPSC Class	39121600
UOM	EA
Vendor Product	SM36A80-500
Current	80 Amp
Connection Type	Shrouded Line and Load
Height	119.5mm
Depth	116.4mm
Frequency	50/60 Hz
Interrupt Capacity	6 kA
Mounting Method	DIN Rail/Surface
IP Rating	IP2X
Number Of Poles	4 Pole
Temperature	-40 to 85 deg C
Terminal Connection	0.75 to 35 sq-mm
Trip Sensitivity	500 mA
Voltage	115-240 Volt
Width	80mm
