Panduit Quick Connect Female Insulated Double Grip 0.5-1mm 6.3mm Tab Red Nylon

Description

QC Terminal Female Insulated Double Grip, 22-18 AWG, 600 Volt, 6.3 mm Tab Size, 7.1 mm Wire Strip Length, Butted Seam Type, Free Hanging Mounting, Brass Base Material, Copper, Nylon Insulation, Red Insulation, Tin Plated, 3.4 mm Wire Insulation Diameter, 125 deg C, 21.3 mm Length, 8.9 mm Width, 5.6 mm Height, 25 Pack

Key Specifications

SKU	PANEDNF18-250FIB-Q
Brand	Panduit
Range Name	StrongHold
Product Type	Quick Connect Terminals

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	25
UNSPSC Class	39121400
UOM	EA
Vendor Product	EDNF18-250FIB-Q
Base Material	Brass
Conductive Material	Copper
Finish	Tin Plated
Height	5.6 mm
Insulation Colour	Red
Insulation Material	Nylon
Mounting Method	Free Hanging
Pack Size	25 Pack
Seam Type	Butted
Tab Size	6.3 mm
Temperature	125 deg C
Voltage Rating	600 Volt
Width	8.9 mm
Wire Strip Length	7.1 mm
Wire Insulation Diameter	3.4 mm
