Sprecher+Schuh Contactor Control Relay Switching 4 Pole 10/6A 48VDC 2NO-2NC Conventional DIN Rail Mount

Description

Contactor Control Relay Switching, AC15 Rating: 240 Volt at 10 Amp/415 Volt AC at 6 A, 48 Volt DC, 2NO+2NC, 4 Pole, DIN Rail/Base Mount, IP20, Please Note: Conventional Coil

Key Specifications

Barcode (EAN-13)	9321807226501
SKU	S&SCS8C-22Z-48VDC
Brand	Sprecher+Schuh
Range Name	CS8
Product Type	Contactors Switching

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Several contactor families provide a wide variety of contactor sizes, offering economy and selection Compact dimensions saves panel space Features low-profile design and 45 mm width, permitting the use of enclosures with shallow mounting depths Utilises same accessories as CA8 contactors which require no additional panel space Available in AC or DC control coil versions to suit your application requirements DIN rail mountable for easy installation
Standard Pack Size	1
UNSPSC Class	39121500
UOM	EA
Vendor Product	CS8C22Z48VDC
Contact Configuration	2 Normally Opened & 2 Normally Closed
AC15 Rating	10 Amp 240 Volt/6 Amp 415 Volt
IP Rating	IP20
Number Of Poles	4 Pole
Mounting Method	DIN Rail/Base
Operating Coil Voltage	48 Volt DC
Please Note	Conventional Coil
