Serveredge Alpha Series Fibre Optic Cable Singlemode Loose Tube OS2 12 Fibre Polyamide-12

Description

Fibre Optic Cable Singlemode Loose Tube, 12 Fibre, OS2, Singlemode, <0.35 dB/km at 1310 nm, <0.23 dB/km at 1550 nm Attenuation, 204 mm Bend Radius, 2 kN Tensile Strength, Compound Thixotropic Jelly Tube, Blue/Five Black Filler Colour Sequence, Inner: HDPE/Outer Jacket: Polyamide-12 Sheath, 30 to 70 deg C, 10.2 mm +/-0.5 mm Outside Diameter

Key Specifications

SKU	SEVPTL-12C-OS2
Brand	Serveredge

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Non-metallic and anti-buckling element FRP rod used as central strength member Water swellable yarn helically wrapped over central strength member Loose buffer tubes fully filled Thixotropic Jelly Loose buffer tubes S-Z Stranded Cable core is wrapped with water swellable Tape Cable core is wrapped with water swellable Tape HDPE black for inner sheath Outer jacket of polyamide-12, Blue Particularly robust cable and insect resistance Complies with relevant ITU, IEC, standards & specifications
Standard Pack Size	1
UNSPSC Class	43223300
UOM	MTR
Vendor Product	PTL-12C-OS2
Attenuation	<0.35 dB/km at 1310 Nm - <0.23 dB/km at 1550 Nm
Bend Radius	204 mm
Colour Sequence	Blue/Five Black Filler
Fibre Count	12
Fibre Mode	Singlemode
Fibre Type	OS2
Outside Diameter	10.2 mm +/-0.5 mm
Sheath Material	Inner: HDPE/Outer Jacket: Polyamide-12
Temperature	30 to 70 deg C
Tensile Strength	2 kN
Tube Filling	Compound Thixotropic Jelly
