Teco Electric Motor Squirrel Cage Induction 4P 0.37kW 1Ph 240V D71 Frame Flange Mount

Description

Electric Motor Squirrel Cage Induction, 240 Volt AC, 2.6 Amp, 0.37 kW, 50 Hz, 1 Phase, 1400 rpm, 4 Pole, IP55, Frame: D71, Shaft Size: 14 mm, Duty Cycle: S1, Ball Bearing, Torque: 35 N/m, Flange Mount, Insulation Class: Class F, <80 deg C, Aluminium, Teal, 255 mm Length x 205 mm Height

Key Specifications

SKU	TEO134/0.37MV4
Brand	Teco
Range Name	Monarch Single Phase
Product Type	Motors SCIM

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Metric frame motor to AS1359 Totally enclosed fan cooled Motors less 1.5 kW are 240 Volts Single Phase 50 Hz and include manual overload protection Motors 1.5 kW and larger are 240/480 volts single phase 50 Hz Class F insulation with a Class B temperature rise Continuous rated, duty type S1 Capacitor start, capacitor run for good starting torque Alloy Frame motor with top mounted terminal box
Standard Pack Size	1
UNSPSC Class	26101100
UOM	EA
Vendor Product	134/0.37MV4
Colour	Teal
Current	2.6 Amp
Bearing Type	Ball
Frame	Size D71
Height	205 mm
Frequency	50 Hz
Insulation Class	Class F
IP Rating	IP55
Horsepower	0.37 kW
Mounting Method	Flange
Material	Aluminium
Number Of Poles	4 Pole
Phase	1 Phase
Shaft Size	14 mm
Speed	1400 rpm
Temperature	<80 deg C
Voltage	240 Volt AC
Torque Rating	35 N/m
