AFL U/UTP Data Cable Cat5e 4 Pair 24AWG Polyethylene/LSZH Grey 305M

$AFL\AFL_No_Image_Available.jpg$

Description

U/UTP Data Cable Cat5e 4 Pair, 24 AWG, 100 MHz Bandwidth, Cat5e U-UTP Unscreened Cable, 4 Pair, 50 N Max. Pulling Force, Soft Plain Copper Conductor, Polyethylene Insulation, LSZH Sheath, Grey Sheath,-15 to 70 deg C, 305 mtr Length, 5mm +/-0.5mm Outside Diameter

Key Specifications

SKU	ATAAFLCABLE5U-GY-L
Brand	AFL
Product Type	Cat5E Cable

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Standard Pack Size	305
UNSPSC Class	43223300
UOM	BX
Vendor Product	AFLCABLE5U-GY-L
Cable Type	Cat5e U-UTP Unscreened
Conductor Size	24 AWG
Conductor Material	Soft Plain Copper
Frequency Bandwidth	100 MHz
Insulation Material	Polyethylene
Max. Pulling Force	50 N
Pair Count	4 Pair
Outside Diameter	5mm +/-0.5mm
Sheath Colour	Grey
Sheath Material	LSZH
Temperature	-15 to 70 deg C
