CCG Cable Gland Reducer M20 Male to M16 Female 316/316L Stainless Steel/Aluminium/Brass Exdb/Exeb/Exta/ExnR

$CCG\CCG_Reducer_RM.JPG$

Description

Cable Gland Reducer, M20 Male to M16 Female Cable Gland Size, 15 mm Thread Length, Ex db Ex eb Ex ta Ex nR, 27 mm Width Across Flats, 30.4 mm Width Across Corners, IP65/66/68, 316/316L Stainless Steel/Aluminium/Brass Body, HDPE/PTFE Gasket, Nickel Plated

Key Specifications

SKU	CCGRM020M016E
Brand	CCG
Range Name	EX Reducer

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	Precision manufactured from high quality brass (marine grade electroless nickel plated), available in aluminium, stainless steel 316/316L on request Converts mismatching threads to the required thread
Standard Pack Size	1
UNSPSC Class	39121400
UOM	EA
Vendor Product	RM020M016E
Body Material	316/316L Stainless Steel / Aluminium / Brass
Finish	Nickel Plated
Cable Gland Size	M20 Male to M16 Female
For Use With	General Industrial and Hazardous Area Installation
Gasket Material	HDPE / PTFE
Hazardous Area Rating	Ex db Ex eb Ex ta Ex nR
IP Rating	IP65/66/68
Temperature	-60 to 95 deg C (HDPE) / -60 to 160 deg C (PTFE)
Thread Length	15 mm
Width Across Corners	30.4 mm
Width Across Flats	27 mm
