ICAR AC Motor Run Capacitor Standard Duty 400/450V 70µF
Loading...
Description
AC Motor Run Capacitor Standard Duty, 400/450 Volt AC, Capacitance: 70 microF, For Use With: AC Motor, 6.3 mm Double Quick Connect Termination, Operation Class: P0, Climate Category: 40/85/21, Case Size : 50 mm x 116 mm
Key Specifications
| SKU |
CMMYU270010A000
|
|---|---|
| Brand |
ICAR
|
| Product Type |
Motor Capacitors
|
Technical Specifications
Looking for something specific? Search with keywords to help filter your required specifications.
Additional Information
| Standard Pack Size | 1 |
|---|---|
| UNSPSC Class | 26101400 |
| UOM | EA |
| Vendor Product | YU270010A000 |
| Capacitance | 70 µF |
| For Use With | AC Motor |
| Climate Category | 40/85/21 |
| Operation Class | P0 |
| Please Note | Case Size : 50 mm x 116 mm |
| Voltage | 400-450 Volt AC |
| Termination | 6.3 mm Double Quick Connect |
