Fluke Series 280 Data Logging Multimeter True-RMS 1000VAC/DC W/TrendCapture

Description

Data Logging Multimeter True-RMS, 50 mV/500 mV/5 Volt/50 Volt/500 Volt/1000 Volt AC/DC, 500 uA/5000 uA/50 mA/400 mA/5 Amp/10 Amp AC/DC, 99.999 Hz/999.99 Hz/9.9999 kHz/99.999 kHz/999.99 kHz, 500 Ohm/5 kOhm/50 kOhm/500 kOhm/5 MOhm/50 MOhm/500 MOhm, 6 x AA Alkaline Battery, -20 to 55 deg C, 50 mV/500 mV/5 Volt/50 Volt/500 Volt/1000 Volt Resolution, 1 nF/10 nF/100 nF/1 uF/10 uF/100 uF/1000 uF/10 mF/100 mF Range, 0.4% AC/0.025% DC Accuracy, 6 cm Length x 10.2 cm Width x 22.2 cm Height

Key Specifications

Barcode (EAN-13)	095969354103
SKU	FLU289
Brand	Fluke
Range Name	Series 280

Technical Specifications

Looking for something specific? Search with keywords to help filter your required specifications.

Additional Information

Features	TrendCapture graphically displays logged data session to quickly determine whether anomalies may have occurred Zoom on trend provides unprecedented ability to view and analyze TrendCapture data zoom in up to 14 times Selectable AC filter (smoothing mode) helps display a steadier reading when the input signal is changing rapidly or noisy Low Pass filter for accurate voltage and frequency measurements at the same time on adjustable speed motor drives and other electrically noisy equipment LoZ Volts, Low impedance voltage function for eliminating ghost voltages Also reco mmended when testing for absence or presence of live power Adjustable recording and auto hold thresholds, specify a percentage change in the readings that begins a new event Large 50,000 count, 1/4 VGA dot matrix display with white backlight Logging function with expanded memory for unattended monitoring of signals over time Using on-board TrendCapture users can graphically review logged readings without needing a PC Store up to 15,000 recorded events Save multiple logging sessions before PC download is necessary Two terminal 50 Ohm range with 1 milliOhm resolution, 10 mA source current Useful for measuring and comparing differences in motor winding resistance or contact resistance
Standard Pack Size	1
UNSPSC Class	41113600
UOM	EA
Vendor Product	FLU289
Current	500 uA-5000 uA-50 mA-400 mA-5 Amp-10 Amp AC/DC
Dimensions	6c m Length x 10.2 cm Width x 22.2 cm Height
Frequency	99.999 Hz/999.99 Hz/9.9999 kHz/99.999 kHz/999.99 kHz
Power Supply	6 x AA Alkaline
Product Type	simple
Resistance	500 Ohm/5 kOhm/50 kOhm/500 kOhm/5 MOhm/50 MOhm/500 MOhm
Temperature	-20 to 55 deg C
Voltage	50-500 mV 5-50-500-1000 Volt AC/DC
